PRODUCTS

Specification

Product NameHastelloy C-276 (UNS N10276, 2.4819) Seamless Pipes & Tubes
Equivalent MaterialsHastelloy C-276, INCONEL Alloy C-276, HC-276, Hastelloy C-276, UNS N10276, W.-Nr. 2.4819, ATI C-276, Nicrofer 5716 hMoW-Alloy C-276, NAS NW276, NiMo16Cr15W
Type Seamless
ShapeSquare / Rectangular / Round / Special-shaped
Executive StandardASTM B575/ASME SB-575、ASTM B574/ASME SB-574、ASTM B622/ASME SB-622、ASTM B619/ASME SB-619、ASTM B366/ASME SB-366、ASTM B564/ASME SB-564
Available GradesStainless steel 301 / 302 / 303 / 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 904L / 2205 / 2507 / 321 / 32760 / 253MA / 254SMo / 410 / 420 / 430 / Custom465 / XM-19 / S31803 / S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65Nitronic 30 / Nitronic 32 / Nitronic 33 / Nitronic 40 / Nitronic 50 / Nitronic 60  etc..
Monel 400 / Monel K-500
Inconel 600 / Inconel 601 / Inconel 625 / Inconel 617 / Inconel 690 / Inconel 718 / Inconel X-750 / Inconel 713C / Inconel 713LC
Incoloy A-286 / Incoloy 800 / Incoloy 800H / Incoloy 800HT
Incoloy 825 / Incoloy 901 / Incoloy 925 / Incoloy 926
Nimonic 75 / Nimonic 80A / Nimonic 90 / Nimonic 105 / Nimonic C263 / L-605
Hastelloy B / Hastelloy B-2 / Hastelloy B-3 / Hastelloy C / Hastelloy C-276 / Hastelloy C-22
Hastelloy C-4 / Hastelloy C-2000 / Hastelloy G-35 / Hastelloy X / Hastelloy N
PH stainless steel 15-5PH / 17-4PH / 17-7PH
Out diameter Seamless Pipe 6MM - 1174MM or customized
Thickness Seamless Pipe 1mm - 80mm or customized
Max LengthSeamless Pipe 12000mm or customized
Finish 2B, Pickling, Polished, Brushed, Sandblast, BA, EP
Packing waterproof polybag, wooden box, end cap, wooden crame/pallet
Inspection TUV,SGS,BV,ABS,LR and so on
Application Large chemical containers for chemical industry, transportation, natural gas and petroleum industry, paper industry, environmental pollution control equipment, etc.
Processing Service Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining
Deformation processing :  Bending / Cutting / Rolling / Stamping
Welded
Forged
Delivery Time7-40 days
Trade TermFOB CIF CFR CIP DAP DDP EXW
PaymentT/T, L/C,D/A,D/P, Western Union,MoneyGram,According to customer requirements payments for offline orders.
TransportationBy air, by sea, by train, by truck
SampleFree
WarrantyTrade assurance after sales service


Overview of Hastelloy C-276 characteristics:

Hastelloy C-276 (N10276) has excellent corrosion resistance to most corrosive media under oxidation and reduction conditions. Excellent resistance to pitting corrosion, crevice corrosion and stress corrosion cracking. The alloy is suitable for various chemical process industries containing oxidizing and reducing media. The higher content of molybdenum and chromium makes the alloy resistant to corrosion by chloride ions, and the element tungsten further improves its corrosion resistance.


Hastelloy C-276 is one of the only materials that can resist the corrosion of moist chlorine, hypochlorite and chlorine dioxide solution. The alloy has significant corrosion resistancetohigh-concentration chlorinated salt solutions (such as chlorinated Iron and copper chloride).


Chemical Composition of Hastelloy C-276 (N10276):

alloy%NiCrMoFeWCoCMnSiVPS
Hastelloy C-276Smallmargin14.51543-------
Big16.51774.52.50.0110.080.350.040.03


Physical properties of Hastelloy C276:


Density g/cm3Melting point °CThermal conductivity λ/(W/m•℃)Specific heat capacity J/kg•℃Elastic modulus GPaShear modulus GPaResistivity μΩ•mPoisson's ratioCoefficient of linear expansion a/10-6℃-1
8.91325137010.2(100℃)407208 791.25
11.7(20~100℃)

The small value of the mechanical properties of Hastelloy C276 alloy at room temperature:



alloystatetensile strengthRm N/mm2Yield StrengthRP0.2 N/mm2ElongationA5%
Solid solution69028340


Specification & Standard:

alloyPlankBarwelding rodWelding wireSeamless pipeWelded pipePipe fittingsForging
Hastelloy C-276 (N10276)SB575 B575SB574 B574ENiCrMo-4ERNiCrMo-4SB622 B622SB619/B619SB366SB564
SB626/B626B366B564


Application of Hastelloy C-276 (N10276):

Hastelloy C-276 has been widely used in the chemical and petrochemical fields, such as in components and catalytic systems that contact chloride-containing organics. This material is especially suitable for use in high temperature, mixed with impurities of inorganic and organic acids (such as formic acid and acetic acid), and seawater corrosive environments.


Other application areas:

● Pulp and paper industry, such as digestion and bleaching vessels

●Washing tower, reheater, wet steam fan, etc. in FGD system

●Equipment and components operating in acid gas environment

●Reactor for acetic acid and acid products

●Sulfuric acid condenser

●Methylene diphenyl isocyanate (MDI)

●Production and processing of impure phosphoric acid
